Automatic Computer Controlled Hydraulic Servo Steel Rebar Tensile Universal Testing Machine
Thumbnail 1 Thumbnail 2 Thumbnail 3 Thumbnail 4 Thumbnail 5 Thumbnail 6
Manufacturer

Automatic Computer Controlled Hydraulic Servo Steel Rebar Tensile Universal Testing Machine

USD 2394,32 / piece
Preis variiert je nach Menge und Spezifikationen
Mindestmenge 1 piece
Kategorie Instruments & Meters
Bestellung aufgeben
Shanghai Hongke Instrument Technology Co., Ltd.

China

Manufacturer
26
Jahre
98%
Antwortrate
24h
Antwortzeit
Jetzt chatten
Mehr von diesem Lieferanten
Kundenspezifische kompakte Hochgeschwindigkeits-Zugprüfmaschine für die Separator-Leistungsprüfung
Kundenspezifische kompakte Hochgeschwindigkeits-Zugprüfmaschine für die Separator-Leistungsprüfung
USD 9432,15
High Performance Safe High Temperature Aging Test Chamber for Semiconductor Industry
High Performance Safe High Temperature Aging Test Chamber for Semiconductor Industry
USD 9432,15
Electric Desktop Digital Universal Testing Machine for Plastic Films
Electric Desktop Digital Universal Testing Machine for Plastic Films
USD 2394,32
High Efficiency High and Low Temperature Electric Material Universal Testing Machine
High Efficiency High and Low Temperature Electric Material Universal Testing Machine
USD 2394,32
Computerized No Rotor Rheometer for Rubber Material Rheology Testing
Computerized No Rotor Rheometer for Rubber Material Rheology Testing
USD 10883,00
Tensile Electric Universal Testing Machine for Composite Materials
Tensile Electric Universal Testing Machine for Composite Materials
USD 2394,32

Produktbeschreibung

Keine detaillierte Beschreibung verfügbar. Bitte senden Sie eine Anfrage.

Automatic Computer Controlled Hydraulic Servo Steel Rebar Tensile Universal Testing Machine
Automatic Computer Controlled Hydraulic Servo Steel Rebar Tensile Universal Testing Machine

Technische Spezifikationen

Model NO.KE-YA07
After-sales ServiceProvided
WarrantyProvided
TypeUniversal Testing Machine
Accuracy Grade1
Load WayElectronic Load
Control10-Inch Touchscreen Control System
Power Source220V,50Hz
Maximum Test Forcekn600kN
Relative Error of Test ForceWithin±0.5%
Measuring Range of Test Force2%-100% of Maximum Test Force
Isokinetic Stress Control Range2-60 N
Stress Rate Error≤±0.5%
ISO-Velocity Displacement Control Range0.05-100mm/Min
Relative Error of Displacement Speed≤±0.5%
Jaw Clamping MethodHydraulic Clamping
Round Specimen Clamping Diameter Range6mm-φ40mm
Flat Specimen Clamping Thickness Range0-30mm
Flat Specimen Clamping Width80mm
Maximum Tensile Test Space700mm
Maximum Compression Test Space600mm
Maximum Moving Speed of Piston0-100 mm/Min
Size of Upper and Lower Pressure Plateφ 160mm
Transport PackageProvided
OriginChina
